| Processor System | CPU | I7-4710HQ | I7-4700EQ |
| Base Frequency | 2.5 GHz (Qaud-Core,Octa-Thread) | 2.4 Ghz (Qaud-Core,Octa-Thread) |
| Max Turbo Frequency | 3.5 GHz | 3.4 Ghz |
| Smart Cache | 6MB | 6MB |
| BIOS | AMI UEFI 64 Mbit |
| Memory | Technology | Dual channel DDR3L 1600MHz | Dual channel DDR3L 1600MHz w/ ECC |
| Max. Capacity | Onboard 8GB,1x DDR3L SODIMM socket max. to 8GB |
| Graphics | Controller |
Intel® HD Graphics 4600 |
| Processor Graphics | DirectX 11.1, OpenGL 4.0 |
| Full AVC/VC1/MPEG2 HW Decode |
| Ethernet | Controller | Intel® I350-AM4 Quad Port Gigabit Ethernet Controller to backplane; 2x I211 to front panel |
| WatchDog Timer |
| Output System reset, Programmable counter from 1 ~ 65535 minutes/ seconds |
| Storage | Onboard Flash | 64G/128G SATA |
| MSATA | 1x Full-size |
| Front I/O | Ethernet | 2x RJ-45 10/100/1000BASE-T |
| USB | 2x USB 3.0 |
| Serial (COM) | 1x RS-232 on RJ-45 connector(CISCO standard) |
| Miscellaneous | XMC, VGA |
| VPX Interface | P1 | 2x PCIEx8 Gen3 configurable to 1 x 16 or 4 x 4 |
| P2 | 2x PCIEx8 Gen3 configurable to 1 x 16 or 4 x 4 |
| P4 | 12d XMC IO; 2x 10/100/1000BT (alternative of SerDes) from I350 |
| P5 | 2x USB3.0; 2x USB2.0; 2x SATA-III; DDI x1(Configurable to HDMI/DVI/DP ); EDP x1; 2x UART(TTL) |
| P6 | 2x 10/100/1000BT; Audio from ALC662; 5x USB 2.0; PS-2 KB/MS; 2x UART(RS232) |
| Power | Power Consumption (Typical) | 60W |
| Environment | Operating | -40 °C ~ 70 °C (Operating humidity: 40 °C @ 95% RH Non-Condensing) |
| Non-Operating | -40 °C ~ 85 °C and 60 °C @ 95% RH Non-Condensing |
| Physical Characteristics | Dimensions (L x W) | 4HP, 233.35 x 160 mm (9.2' x 6.3') (W x D) |
| Weight | 1kg |
| Height | Top Side: 14.5 mm; Bottom Side: 2 mm; PCB: 1.6 mm |
